| 产品特性 : | 不间断电源 | 品牌 : | Nipron |
| 型号 : | eNSP4-500P-SA0-H1V | 上市时间 : | 2010 |
| 配件类型 : | 不间断电源 工控机电源 | 产品尺寸 : | 150Wx86Hx140D |
| 产品重量 : | 1.8 | 快出货时间 : | 30天以上 |
| 发票 : | YES | 售后服务 : | 店面三包 |
| 包装清单 : | NO |
Nipron eNSP4-500P-SA0-H1V UPS 不间断电源Nipron BS13A-EC400/422F 电池组批发Nipron 交换式电源供应器Nipron 开关电源Nipron工作站电源Nipron不间断电源Nipron 怪兽级电源Nipron 索尼贴片机电脑电源Nipron 工控机电源Nipron 全线工业电源批发及电源维修
One-second Backup Power Supply
- High capacity ATX12V power supply capable of one-second backup at blackout with a capacitor package connected(typical value at 180W output)
- Advantages of capacitor package
- Maintenance free (no need for periodical replacement)
- Corresponds to low- and high-temperature environment (0 to 60 deg C
- Quick charging in 2 minutes corresponding to frequent blackout- Light weight: 1.4kg typical
-Equipped with AC_FAIL signal (delivered at power failure: RS232C,TTL)
| Compatible case size | PS2 | |
| Outline drawing | 150Wx86Hx140D | |
| Weight | 1.80 kg typ | |
| Input Voltage | AC | 85-264V |
| DC | 380V (Dedicated capacitor package only) | |
| Efficiency | AC | 73% typical at AC100V and 77% typical at AC240V |
| DC | 80% typical | |
| Power factor | 99% typical at AC100V and 97% typical at AC240V | |
| Input changeover system | Worldwide | |
| AC, DC input | DC input is for dedicated capacitor package. | |
| Safety | UL60950, CSA C22.2 No.60950 (c-UL), EN60950, CE Marking (IEC62368-1) | |
| High frequency current regulation | Compliant with IEC61000-3-2 (Ed. 2.1) Class D and EN61000-3-2 (A14) Class D | |
| EMI standard (Input feedback noise) | Compliant with VCCI Class B FCC Rules Class B and EN55022 Class B | |
| CE marking | Low voltage and EMI directive and RoHS2.0 | |
| EMS immunity | Electrostatic discharge to meet EN61000-4-2 Radioactive radio-frequency electromagnetic fields to meet EN61000-4-3 Fast transient burst to meet EN61000-4-4 Lightning surge immunity to meet EN61000-4-5 Conductive radio-frequency electromagnetic field to meet EN61000-4-6 Power frequency magnetic field immunity to meet EN61000-4-8 Voltage dips and fluctuation to meet EN61000-4-11 | |
| MTBF | 95,000H | |
| Operating temperature | 0 to 45 deg C with full-load, and to 60 deg C with 70% of load | |
| Leakage current | 0.5mA max. at AC100V, and 1mA max. at AC200V | |
| Cooling systems | Forced air cooling | |
| Output ground connection | Connected to chassis | |
| Signal unit | Supported for SU-RS (RS232C),SU-BU (buzzer),, SU-US2 (USB) | |
| Warranty | Three years after delivery. However, if defects belong to us, the defective unit shall be repaired or replaced at our cost. | |
